Create an accountFrame | Spire Alloy 170mm |
Wheel Size | 29" |
Travel | 170/170mm |
Fork | Fox Float 38 Grip 2 Factory 170mm Travel/44mm Offset |
Rear Shock | Fox Float X2 Factory 2 Position (205x65) |
Headset | FSA NO.55R/57 |
Bottom Bracket | |
Shifter | Shimano XT M8100 |
Rear Derailleur | Shimano XT M8100 |
Cassette | Shimano XT M8100 (10-51t) |
Chain | Shimano XT M8100 |
Chainring | 30T |
Crankset | Shimano XT M8100 (30t/165mm) |
Brakes | Shimano XT M8120 |
Rotors | Shimano RT86 (203mm) |
Seatpost | OneUp Dropper Post |
Handlebar | ANVL Mandrel Alloy 35 SM (800x20) MD/LG/XL (800x30) XXL (800x40) |
Stem | ANVL Swage (40mm) |
Grips | Sensus Lite |
Saddle | ANVL Forge Cromo |
Pedals | N/A |
Front Wheel | DT Swiss EX 1700 Spline 30 | Hub: DT Swiss 350 Straight Pull 36SL |
Rear Wheel | DT Swiss EX 1700 Spline 30 | Hub: DT Swiss 350 Straight Pull 36SL |
Front Tire | Schwalbe Magic Mary, Super Trail, Soft (29x2.4) |
Rear Tire | Schwalbe Big Betty, Super Trail, Soft (29x2.4) |
Sizes | S, M, LG, XL, XXL |
FROM THE MANUFACTURER
Take on the biggest terrain without the penalty, Long travel doesn’t have to mean single purpose
The Spire blends DH bike capability with mid-travel efficiency in such a way it’s almost two bikes in one. A delicately tuned pedaling and pumping platform, super supple beginning stroke sensitivity and all the travel you could ask for makes for a mind bending ride. Haappily climb up to your favorite challenging descent, then cruise on over to your local flow trail and you’ll be rewarded on both ends of the spectrum. Don’t be fooled though, while it’s no one-trick pony, the Spire lives to push your limits. Get in-Spired.
FEATURES
- Lifetime Warranty + crash replacement program
- Pivot technology
- Fully integrated, flush mounted rubber frame protection at all critical areas
- Geo adjust chip for high and low bottom bracket setting
- Size specific chainstays
- Enduromax bearings
- Gear accessory mount under top tube
- Dual crown fork compatible
- Tire clearance up to 2.6"
- Press in headset
- Universal derailleur hanger
GIDDYUP SUSPENSION DESIGN
We want to make it as easy as possible to experience great rear suspension performance. The GiddyUp suspension system is designed to behave intuitively across a broad range of setup. Because, we get it, sometimes you just want to grab your bike and GiddyUp, without checking your setup. When you do, it will always feel good.
With nearly 23% progression and the most current evolution of our GiddyUp suspension kinematic, the Spire has an excellent balance of support and small bump sensitivity. Anti-squat is tuned to enhance pedaling performance and provides a platform to push against when pumping, without sacrificing a bottomless feel when needed.
The GiddyUp suspension layout is tuned to work correctly with both air and coil rear shocks. Riders are able to add or remove volume spacers in the rear air shock to suit their individual riding style and there is plenty of bottom out control with air or coil shocks when things get rowdy. The Spire has 170mm of rear wheel travel when used with the supplied 205mm x 65mm stroke shock. It is also possible to install a shorter, 205mm x 60mm stroke shock to decrease the rear wheel travel to 160mm if you are after a shorter travel experience.
A suggested sag range of 27 - 33% allows the rider to tune the feel of the bike; from a firm and snappy jump and slash mode, to a more supple and active full on party mode. Wherever you end up, you can focus on the trail without remotes, levers or knobs. Just grab your bike and GiddyUp.
![](https://www.transitionbikes.com/images/GiddyUpStokeOptions_Spire2021.jpg)
SIZING & GEOMETRY
Measured in mm
![](https://www.transitionbikes.com/images/AllSizesDiagram2020.png)
![](https://www.transitionbikes.com/images/SBGSizingChartFINALII.png)
Don't forget your pedals!
We recommend that you call our shop to discuss bike sizing and styles with the bike geeks at the shop. We have more to choose from than our website shows, and our bikes are available for purchase in our retail store. For the most accurate inventory and best advice, call 530-582-0909. We are open 8AM-6PM daily!
** Due to our dealer agreements, this bike is only available to purchase in store. Call to put your name on it today!
