| Frame | TURQ Series Carbon Frame |
| Wheel Size | 29" |
| Travel | 140mm Front | 120mm Rear |
| Fork | RockShox Pike Ultimate |
| Rear Shock | RockShox Super Deluxe Ultimate 190x45 |
| Headset | Cane Creek 40 Integrated |
| Bottom Bracket | SRAM DUB BSA 73 Threaded |
| Shifter | SRAM AXS Pod Controller |
| Rear Derailleur | SRAM X0 Eagle Transmission |
| Cassette | SRAM X0 Eagle Transmission 10-52t |
| Chain | SRAM X0 Eagle Transmission Flattop |
| Chainring | |
| Crankset | SRAM X0 Eagle Transmission 30t 170mm |
| Brakes | SRAM Code RSC |
| Rotors | SRAM Centerline (200mm/180mm) |
| Seatpost | Fox Transfer 31.6mm | XS: 125mm, SM: 150mm, MD: 175mm, LG-XXL: 200mm |
| Handlebar | Yeti Carbon 780mm |
| Stem | Burgtec Enduro MK3 50mm |
| Grips | ODI Elite Pro |
| Saddle | Silverado Custom |
| Pedals | N/A |
| Front Wheel | DT Swiss XM1700 |
| Rear Wheel | DT Swiss XM1700 |
| Front Tire | Maxxis Minion DHF 2.5 EXO |
| Rear Tire | Maxxis Aggressor 2.3 EXO |
| Sizes |
FROM THE MANUFACTURER
Built for riders who demand the best, the LR T3 X0 Transmission is designed to dominate the trail with its elite components and cutting-edge technology. Featuring a TURQ Series carbon frame and Switch Infinity V2 suspension, this bike delivers a perfect blend of agility and rugged durability. Whether we’re navigating technical descents or climbing with ease, the RockShox Pike Ultimate fork and Super Deluxe Ultimate rear shock give us confidence and control. The SRAM X0 Eagle AXS Transmission ensures smooth, wireless shifting, while SRAM Code RSC brakes provide top-tier stopping power. From the lightweight DT Swiss XM1700 wheelset to the precision-engineered Maxxis tires, every component of this bike is designed to elevate our ride. The FOX Transfer dropper post and custom-tuned geometry make sure we're ready for whatever the trail throws at us.
GEOMETRY
| X-Small | Small | Medium | Large | X-Large | XX-Large | |
| ST Length | 345 | 365 | 400 | 440 | 470 | 485 |
| Eff. TT Length | 540 | 571 | 603 | 625 | 652 | 672 |
| HT Angle | 66.5° | 66.5° | 66.5° | 66.5° | 66.5° | 66.5° |
| Eff. ST Angle | 76.5° | 76.5° | 76.5° | 76.5° | 76.5° | 76.5° |
| Actual ST Angle | 71.1° | 71.5° | 71.9° | 72.3° | 72.7° | 73.2° |
| Chainstay Length | 433 | 435 | 437 | 439 | 441 | 443 |
| Wheelbase | 1122 | 1157 | 1191 | 1217 | 1249 | 1274 |
| Est. BB Height | 335 | 335 | 335 | 335 | 335 | 335 |
| Standover | 699 | 709 | 714 | 718 | 720 | 725 |
| HT Length | 92 | 98 | 104 | 115 | 126 | 147 |
| Fork (axle to crown) | 544 | 544 | 544 | 544 | 544 | 544 |
| Fork Offset | 44 | 44 | 44 | 44 | 44 | 44 |
| Stack | 604 | 610 | 615 | 625 | 635 | 655 |
| Reach | 395 | 425 | 455 | 475 | 500 | 515 |
| Front Center | 689 | 722 | 754 | 778 | 808 | 831 |
| Vertical Fork Travel | 119 | 119 | 119 | 119 | 119 | 119 |
