| Frame | Carbon |
| Wheel Size | 29" Front / 27.5" Rear |
| Travel | 170mm Front | 160mm Rear |
| Fork | Fox Performance 38 29", 44mm offset, GRIP — 170mm |
| Rear Shock | Fox Performance Float X — 160mm |
| Headset | Pivot Precision Sealed Cartridge |
| Shifter | Shimano SLX M7100 ISPEC EV 12spd |
| Rear Derailleur | Shimano XT M8100 SGS 12spd |
| Cassette | Shimano Deore M6100 10-51t |
| Chain | Shimano CN-M6100 12spd |
| Chainring | |
| Crankset | Praxis Alloy eCranks E-MTB 34t — 160mm |
| Brakes | Shimano SLX M7120 4-piston |
| Rotors | Galfer Wave 6 Bolt 223mm Front, 203mm Rear |
| Seatpost | SDG Tellis 130-150mm (SM), 150-170mm (MD-XL) |
| Handlebar | Phoenix Race Low Rise Aluminum — 780mm (SM-MD), 800mm (LG-XL) |
| Stem | Phoenix Team Enduro/Trail — 45mm |
| Grips | Phoenix Factory Lock-on |
| Saddle | Phoenix WTB Volt Race (medium width) |
| Pedals | N/A |
| Front Wheel | DT Swiss Hybrid H1900, 30mm — 15x110 |
| Rear Wheel | DT Swiss Hybrid H1900, 30mm — 12x157 |
| Front Tire | Continental Kyrptotal-F 29 x 2.4" Soft Compound Enduro Casing |
| Rear Tire | Continental Kyrptotal-F 27.5 x 2.6" Soft Compound Enduro Casing |
| Drive Unit | Bosch Performance CX Race Edition 750wh |
| Battery | 750wh |
| Display | |
| Extras | N/A |
| Sizes | SM, MD, LG, XL |
FROM THE MANUFACTURER
Relentless Control & Confidence
Built for riders who demand control, the Shuttle LT's 160mm of rear suspension travel and a 170mm Fox 38 fork up front deliver relentless performance on the most rugged trails. Whether you're bombing through rock gardens or sending the biggest drops, this setup absorbs everything while maintaining a lively pedaling platform for efficient climbs. The MX wheel configuration, fitted with Continental Kryptotal tires, enhances grip and control, letting you confidently charge through berms and tackle the gnarliest lines. With unmatched stability and capability, the Shuttle LT pushes you to explore new limits.
Dominant Power & Precision
The Shuttle LT is engineered to dominate every climb and descent with precision, power and finesse. Designed for those who thrive on long-travel eMTB adventures, this bike unlocks new possibilities with the Bosch Performance CX Race Limited Edition Drive unit, delivering an incredible 600 watts of max power. Paired with a 750Wh battery, and expandable to 1000Wh using the PowerMore range extender, the Shuttle LT makes all-day rides an easy reality. The renowned dw-Link suspension system ensures excellent traction on climbs while offering rock-solid control on the most technical descents, creating an unbeatable all-around performer.
FEATURES
- Full Carbon Frame constructed with Pivot's proprietary molding technology
- Bosch Performance CX Race Limited Edition drive unit on every build level
- Power-packed 750Wh battery
- Bosch PowerMore 250 Range Extender compatible
- Adjustable geometry via Pivot Flip-Chip
- 170mm Fox 38 Fork
- 160mm Rear wheel travel
- 223mm Front and 203mm rear rotors
- Mixed-wheel setup
- Clean internal routing with Pivot cable port system
GEOMETRY
*All measurements in cm
| SM | MD | LG | XL | |
| Seat Tube Length | 37 | 40 | 43 | 47 |
| Top Tube Length | 60.5 | 63.0 | 65.0 | 66.9 |
| Head Tube Length | 11 | 12 | 13 | 14 |
| Heat Tube Angle | 64° | 64° | 64° | 64° |
| Seat Tube Angle (eff.) | 76.5° | 76.5° | 77° | 77.5° |
| Chainstay Length | 44.1 | 44.1 | 44.1 | 44.1 |
| BB Height | 35 | 35 | 35 | 35 |
| BB Drop | 1.3 | 1.3 | 1.3 | 1.3 |
| Standover | 68.6 | 69.0 | 69.2 | 69.3 |
| Wheelbase | 123.0 | 125.6 | 128.1 | 130.7 |
| Stack | 63.6 | 64.5 | 65.4 | 66.3 |
| Reach | 44.5 | 46.8 | 48.8 | 51.0 |
